Acoustic Wall Systems
Genie Wall 80 Acoustic System
The Genie Wall 80 Acoustic System is a slimline low profile acoustic lining. Designed to give a high level of reduction whilst maintain as much space possible in your room.
Opti 120 Acoustic Wall System
The Opti 120 Acoustic Wall System is our optimum performance acoustic wall lining. The system looks to limit resonce in the existing structure then add a substantial mass lining with a deep cavity insulated with high performance acoustic insulation.
Opti Wall 140 dBoard Acoustic System
The Opti Wall 140 creates a large separation with an entirely independent void with Maxi resilient bars and our unique acoustic board dBoard.
Genie 150 Acoustic Wall System
The Genie 150 Acoustic Wall System is our deepest independent wall lining system. This wall system is high mass and focuses on isolation and decoupling.
How Do Acoustic Wall Systems Improve Soundproofing?
Acoustic wall systems work by reducing airborne and impact noise through a combination of insulation, isolation, and mass:
- Insulation Layers: Acoustic wall insulation systems such as Opti 120 use deep cavities filled with sound-absorbing materials to dampen resonance and absorb noise.
- Decoupling and Isolation: Systems like the Opti Wall 140 dBoard use resilient bars and independent lining to break the direct sound path, preventing sound energy from transferring.
- Mass-Loaded Barriers: High-density materials like Tecsound membranes and our dBoard product reduce sound transfer by blocking sound waves.
What Are the Different Types of Acoustic Wall Systems?
We have four distinct acoustic wall systems to meet the needs of different projects and spaces. Each system includes the necessary components to deliver effective soundproofing:
Genie Wall 80 Acoustic System
The Genie Wall 80 is a low-profile acoustic wall lining system, designed for projects where space is limited but effective soundproofing is still required.
It uses Genie Clip technology and high-mass Tecsound membranes to provide significant noise reduction in just 80mm depth.
It’s best for residential spaces, offices, and rooms where minimal space loss is essential.
Opti 120 Acoustic Wall System
The Opti 120 is a fully independent acoustic wall system that creates a deep insulated void between the existing wall and the new lining. It reduces resonance in the original structure while adding multiple layers of mass to block sound transmission.
It’s best for high-performance acoustic wall insulation systems in homes, offices, and recording studios.
Opti Wall 140 dBoard Acoustic System
The Opti Wall 140 features a fully independent void, deep fail-safe resilient bars, and our unique high-mass dBoard acoustic wall board. This system eliminates direct sound paths, making it one of the most effective solutions for soundproofing walls.
It’s best for residential and domestic party walls and commercial buildings needing high-level sound insulation.
Genie 150 Acoustic Wall System
The Genie 150 is our deepest acoustic wall system, featuring two levels of isolation and multiple layers of mass. This system is completely independent from the existing structure, offering high-performance noise reduction.
It’s best for professional recording studios and buildings requiring the highest level of soundproofing.
Which Acoustic Wall System Is Right for My Project?
When selecting the right acoustic wall system, here are some of the factors you should consider:
- Acoustic Performance: We have several acoustic wall systems with varying levels of acoustic performance. What level of impact does your project require?
- Noise Type: Do you need to prioritise a solution for the kind of noise you are experiencing? Airborne noise but which type of problem? Speech, music, dogs, TV?
- Space Availability: Assess the available room space. If space is limited, opt for a low-profile system. Deeper systems offer superior acoustic performance but occupy more space.
- Building Type: You’ll need to match your system to your project’s purpose, whether that’s a residential building, an office, or more unique spaces like recording studios or cinemas.
For specific guidance on the best acoustic solution for your project, we’re here to help. You can contact us online or give us a call to speak to our experts.
Our Experts On Acoustic Wall Systems
The Team At SIS Says:
"We have a number of tried and tested acoustic wall systems to suit your property, requirements, and project. Our acoustic wall systems offer high mass, isolation, and insulation solutions to restore the quiet space you are looking for."
Find the Acoustic Wall System You Need at Sound Insulation Store
We’re on hand to specify the best acoustic wall system to fit your needs and budget. With over 30 years of industry experience, we’ve hand-selected the highest-quality materials and designed our own soundproofing solutions to offer reliable noise control and comply with UK building regulations. Speak to our team today for assistance in soundproofing your space.
Acoustic Wall System
Can acoustic wall systems be installed on existing walls?
Yes, many acoustic wall systems are designed for retrofit installation onto existing walls without extensive construction. For example, slimline, low-profile systems like our Genie Wall 80 Acoustic System – which is only 80mm (3in) deep off the wall – can be directly fixed to minimise space loss and disruption.
Our high-performance systems with an independent free-standing stud wall, such as the Opti Wall 140 dBoard Acoustic System, require additional installation steps but can still be installed without major structural changes.
Do you have to cover the whole wall for soundproofing?
Covering the entire wall is essential. For optimal performance and to avoid sound leakage, full coverage with an acoustic wall insulation system is the most effective approach. You may also need to consider lining the flanking walls. Generally treating the main separating element will offer significant reduction.
Our systems include all the insulation and high-mass materials required, as well as fixings and acoustic sealant for optimal performance.
How much sound reduction can I expect from an acoustic wall system?
Sound reduction varies depending on the system’s depth and components. Low-profile systems typically provide good reduction of everyday household noises. Deeper, independent systems, such as the Genie 150 Acoustic Wall System, provide a higher level of soundproofing ideal for spaces like studios or home offices.
